1.Pipe material: The counterweight frame is made of high-quality rectangular steel pipe 120*50mm, and the main frame is made of high-quality rectangular steel pipe 100*50mm, with a thickness of 3mm.
2.Guard: ABS fully enclosed streamlined door assembly is adopted to maximize the safety of users and others
3.Appearance: Equipped with ABS screw cap and pulley block cover, the whole machine is more concise and beautiful
4.Guide rod: high hardness, high-gloss chrome plating: 19mm in diameter
5.Counterweight: cold-rolled steel counterweight piece, weight 110kg
6.Bolt: high-hardness, high-gloss chrome plated, 8mm diameter counterweight bolt
7.Handle: made of high toughness PVC material, aluminum alloy sealing cap, round and comfortable
8.Adjustment: the seat cushion has multiple positions and height adjustable
9.Soft bag: seat cushion and back cushion use one-time forming sponge foaming process to prevent deformation
10.Bracket: equipped with a bottle cage with an inner diameter of 78mm
11.Transmission: use maintenance-free and self-lubricating steel wire rope with a diameter of 6mm, and high-quality universal joint 12.connection with the frame to extend the service life of the wire rope
13.Pulley: Made of high-quality fiber reinforced U-shaped nylon non-slip, anti-falling, precision bearing pulley, diameter 105mm
14.Foot pad: The foot pad is made of rubber material, the thickness is 20mm, and it has the function of shock absorption.
15.Description: The body has fitness instruction stickers and warning stickers
16.Track: The product adopts an ergonomic movement structure to make the movement closer to the direction of muscle contraction, and more scientifically and effectively to ensure the training effect
Product Description
SPECS
Product Length:57.87 " (147cm)
Product Width: 40.94" (104 cm)
Product Height: 60.24" (153 cm)
Machine Weight: 551.16 lbs. (250kg)
Gross Weight: 619.50 lbs. (281kg)
Weight Stack: 242.51 lbs. (110 kg)
Packaging Information
Length: 66.14" (168cm)
Width:42.52" (108 cm)
Height: 15.75" (40cm)
Volume: 0.73 ( m³)
